2 kVA 110V/220V 60Hz/50Hz Frequency Converter

2 kVA static frequency converter, change single phase 110V 60Hz power to 220V 50Hz in an easy way, changeable voltage & frequency (V/Hz) separately with pure sine wave output for general home devices.
Delivery date: 15 - 30 days

2 kVA 110V 60Hz to 220V 50Hz static (solid state) frequency converter with built-in step up transformer, also can change 220V 50Hz to 110V 60Hz power, changeable frequency and voltage per your request.


Model HZ-50-1102
Capacity 2 kVA
Dimension 550*400*670mm
Weight 60 kg
Input Voltage 1 Phase 2 Wire: 110V/120V, 220V/230V/240V ± 10% (option *)
Frequency 50 Hz, 60 Hz or 400 Hz ± 5%
Output Voltage, current 110V Setting (Low grade): 0-150V, 16.8A
220V Setting 0-300V (High grade): 0-300V, 8.4A
Load stabilization Rate ≤±1%
Frequency 50Hz, 60Hz up to 400Hz adjustable
Frequency Stability ≤±0.01%
Harmonic Distortion Pure Sine Wave ≤2%
Frequency meter 4 digit, digital frequency meter, resolution 0.1Hz/Step
Voltmeter 4 digit, digital voltage meter, resolution 0.1V
Ammeter 4 digit, digital ammeter, resolution 0.1A
Watt meter 4 digit, digital Watt meter, resolution 0.1W
Protection With overload, short circuit, over temperature
Instantaneous power failure protection and alarm device
Working Environment Temperature 0 - 40 deg.℃
Humidity 0 - 90% (Non condensation)
Warranty 18 months

* The input voltage is factory selected.

Tips: Where is frequency converter being used?
The power supply in UK is 50 Hertz 230V AC, in USA its 60 Hertz 110V AC. So, if you want to use an appliance from USA in UK, not only need to step-down voltage to 110Vac, but will have issues with the frequency. So any appliance with a motor, for example, microwave ovens, CD/DVD players, analogue clocks etc. would all respond differently to a lower frequency. In such situations, you will need a static (solid state) frequency converter. By using a static frequency converter, you can convert 220V/230V/240V 50Hz to 110V/120V 60Hz, vice versa. Adjustable output voltage and frequency function allows you converting fixed voltage & frequency power course to conform with your appliances.

Download PDF, DOC...
PDF: 50Hz/60Hz Frequency Converter Manual
